The MARSHINE Model DLSS Cable Feeder can streamlines the process of laying power lines, fiber optics, and underground conduits. With the electric power pulling cable instead of the labor force, the cable feeder can ensures the seamless operation, improve the construction efficiency while maintaining the required standards of safety and performance.
Product Parameter
| Item number | 21102 | 21103B | 21105 | 21106 |
| Model | DLSSJ5 | DLSSJ5B | SSJ5V | DLSSJ8A |
| Diameter of suitable cable(mm) | φ60-140 | φ40-150 | φ40-130 | φ50-200 |
| Pull Force(KN) | 5 | 5 | 5 | 6 |
| Speed(m/min) | 6.5 | 6.5 | 6.5 | 6.5 |
| Motor Power(kw) | 1.5 | 2x0.55 | 1.5 | 2x0.75 |
| Supply Voltage(V) | AC380 | AC380 | AC380 | AC380 |
| Dimension(mm) | 948x470x542 | 900x617x452 | 1060x437x690 | 1000x657x464 |
| Weight(kg) | 203 | 190 | 148 | 220 |
| Crawler Arrangement | Up-down ConfigurationCrawler | Right and left Configuration crawler | V type configuration crawler | Right and left Configuration crawler |
| Remark | Can add auxiliary winch | Can add auxiliary winch | the press pulley removable | Can add auxiliary winch |
Product Feature
This MARSHINE Model DLSS Cable Feeder equipped with a powerful electric motor to ensure stable and consistent cable feeding. It can precisely control the cable movement to adapt to the different installation environments. Been made of durable alloy steel, it can withstand the harsh construction site conditions with its simple mechanical structure and continuous power supply. This tool is easy to operate with minimal training, while the set up and maintain are simple. With its compact constructions and ability to provides a reliable cable propulsion for cables, it is suitable for long-distance pulling.
Product Application
The MARSHINE Model DLSS Cable Feeder is suitable for cable trenches, tunnels and shafts in medium and high voltage cable installation projects, can be apply to the cable laying for underground power grids and substations, is widely used by power companies, electrical contractors and cable installation teams.
Product Details
As a practical and essential tool for modern cable installation projects, the MARSHINE DLSS Cable Feeder can providing reliable and labor-saving performance in various working environments.
Place Of Origin: China.
Leading Time: 10days(1-20set).
International Certified: CE, ISO.
Brand: MARSHINE.
